Construction and Decoration Waste Trommel Screen

OUR EMAIL:  Sales@zzsinolion.com

In the urbanization progress, the building repairs garbage as the outcomeof metabolism in the city……

In the urbanization progress, the building repairs garbage as the outcomeof metabolism in the city and has been the burden of developrment in the city,many cities all once faced building to repair garbage to round a trapping ofcity bureau and handled a technical progress along with the garbage, theresources value of the garbage gradually presents, the international top resources recalls to develop rapidly with reborn profession, and the garbage ispraised as “the never dried Up mineral hides” to conceive infnite business opportunities.

The department developrment repair garbage to choose a system equipmentsto mainly used for the entry-level that repairs garbage to choose for cent forcent. easy to follow up buliding garbage the cent choose a processing. fromrepair garbage for cent select heavy quality bulding materal(brick concretepiece, and plank material. etc ) the light material anticipate(the plastics filmslice. paper etc material) smnall grain sandy sol and carry out garbage toreduce to turn. recycing, harmless turned target have to automate degreeGao, use a person ltte, invest itle, circulate cost low etc advantage.

Construction and Decoration Waste Trommel Screen technical parameter:

Model Drum size
(m)
inclination
(°)
Rotation speed
(r/min)
Screen size
(mm)
Max feeding size
(mm)
Capacity
( m3/h)
Power
(kw)
GTS-820 0.8×2 6-10 32 2-20 ≤200 7-30 3
GTS-830 0.8×3 6-10 32 2-20 ≤200 8-50 3
GTS-1020 1×2 6-10 25 2-20 ≤300 10-60 4
GTS-1030 1×3 6-10 25 2-20 ≤300 11-80 4
GTS-1230 1.2×2 6-10 20 2-20 ≤300 12-100 5.5
GTS-1240 1.2×4 6-10 20 2-20 ≤300 14-120 5.5
GTS-1530 1.5×3 6-10 17 2-20 ≤300 16-120 5.5
GTS-1540 1.5×4 6-10 17 2-20 ≤400 18-150 7.5
GTS-1550 1.5×5 6-10 17 2-20 ≤400 20-180 11
GTS-1560 1.5×6 6-10 17 2-20 ≤400 22-200 11
GTS-1850 1.8×5 6-10 14 2-20 ≤400 24-220 15
GTS-1860 1.8×6 6-10 14 2-20 ≤400 26-240 15
GTS-2050 2×5 6-10 12 2-20 ≤400 50-600 22
GTS-2080 2×8 6-10 12 2-20 ≤400 80-700 22
GTS-2260 2.2×6 6-10 10 2-20 ≤400 100-800 30
GTS-2280 2.2×8 6-10 10 2-20 ≤400 120-850 30
